Product Summary

The bgy135 is a VHF power amplifier module. It is used for Mobile communication equipment operating directly from 12 V vehicle electrical systems. Each module consists of two NPN transistor dies together with lumped-element matching components.

Parametrics

bgy135 absolute maximum ratings: (1)DC supply voltage: 15.6 V; (2)VS2 DC supply voltage: 15.6 V; (3)Vi RF input voltage: 25 V; (4)Vo RF output voltage: 25 V; (5)PD input drive power: 300 mW; (6)PL load power: 25 W; (7)Tstg storage temperature: -40 to +100 °C; (8)Th heatsink operating temperature: -20 to +90 °C.

Features

bgy135 features: (1)12.5 V nominal supply voltage; (2)18 W output power.

Diagrams

bgy135 package dimensions
